Shunyata Eiger 6t

Maximum Voltage:
90 – 125 VAC r.m.s. unregulated (US)
220-240 VAC r.m.s. unregulated (EU, AS)


Input Current Ratings:
Input current maximum (US): 20 A
Input current maximum (EU): 16 A
Peak instantaneous current @ 10 ms: >1000 A

Output Current Ratings:
Zone 1 output current max: 20 A
Zone 2 output current max: 20 A
Zone 3 output current max: 20 A


Transient Suppression:
Maximum Transient Protection: 40,000 A @ 8/50 μs

Over-Current Protection:
Hydraulic Electromagnetic Breaker

Wiring System:
10 & 8 gauge ArNi® Conductors
VTX conductor geometry
OFE C10100 copper
Ratings: 600 VAC 105° C

Noise Reduction Technology:
NIC™ Noise Isolation Chambers (patented)
QR/BB™ Module (patented)
Trident Transient Protection Module
CCI™ v4 Noise Filters (3)
KPIP v2™ Process


Noise Supression
Input to Output (100 kHz – 30 MHz): > 50 dB reduction
Zone to Zone (100 kHz – 30 MHz): > 30 dB reduction

Connectors & Sockets:
Input connector: IEC-C19R
Outlets (US): 6 NEMA 5-20P
Outlets (EU): 6 CEE 7/3

KPIP v2 Processing: 4-days

Isolation Zones: 3 individual zones

Vibration Control:
Shunyata Polymer Isolation Footer

Construction:
Powder coated steel chassis – 16 gauge
Anodized aluminum faceplate

GPNR:
Length: 127 mm
Diameter: 38 mm

Dimensions:
Width: 6.2 inches (15.75 cm)
Depth: 9.1 inches (13.12 cm)
Height: 16.7 inches (42.42 cm)
Weight: 12.7 lbs (5.75 kg)
