Shunyata Typhon T30

Maximum Voltage:
90 – 125 VAC r.m.s. unregulated (US)
220 – 240 VAC r.m.s. unregulated (US)
220-240VAC r.m.s. unregulated (EU, AS)

Input Current Ratings:
US/AS maximum continuous current: 30A
EU maximum continuous current: 16A

Output Current Ratings:
US NEMA 2-20 Outlets: 20A
EU CEE7/3 Socket: 16A
Amphenol Outlet: 30A

Transient Suppression:
Maximum transient pulse 40,000 Amps @ 8/50 μs

Over-Current Protection:
Hydraulic electromagnetic breaker

Wiring System:
6 gauge ArNi® VTX-Ag™ buss system
Ratings: 600 V 105° C

Noise Suppression:
Input to Output (100 kHz – 30 MHz): > 50 dB reduction
Zone to Zone (100 kHz – 30 MHz): > 40 dB reduction

Connectors & Sockets:
Inlet: Proprietary 30A Amphenol
Twist-lock outlet: Proprietary Amphenol
US version: 2 NEMA 5-20R
AS version: 2 NEMA 5-20R
EU version: 2 CEE7/3

KPIP v2 Processing: 4-days

Isolation Zones:
3 zones

Vibration Control:
Vibration dampening panels (internal)
AC outlet dampening gaskets
Shunyata Isolation SSF-38 Footer

Construction:
All aluminum chassis
Anodized, brushed aluminum faceplate

Dimensions:
Width: 17 inches (43.2 cm)
Depth: 10 inches (25.4 cm)
Height: 4.4 inches (11.2 cm)
Weight: 17.5 lbs (7.95 kg)
