Rega Elicit MK5

Have questions about this product?

We love answering questions. Talk to an expert now.

z
z

FREE SHIPPING

on all e-commerce orders over $100

TECH SUPPORT

Always Included

The Fono MM MK5 phono stage has been designed to be effective, easy to use, and above all, to reproduce music. The Fono MM MK5 uses a fully discrete, cascaded, complementary amplifier input stage, a configuration designed to optimize the performance of your moving magnet cartridge. Now housed in a brand new redesigned case to match the new Fono MC and Rega’s latest range of electronic components offering a modern look guaranteed to integrate into any hi-fi system.

The perfect partner

The aesthetic design of the Fono MM was as important as the quality of its electrical capabilities, so it benefits from the same updated aluminum case as the Rega Neo and Fono MC amplifier, giving it a design that offers a familiar feel and moreover brings it in line with its illustrious bigger brothers. The RIAA equalization has been split into two stages to minimize interaction. Polyester capacitors have been used in the signal path and polypropylene capacitors are used in the RIAA equalization circuits.

KEY FEATURES

  • Dedicated Moving Magnet stage
  • Simple connectivity and operation
  • Custom case design
  • Two-stage RIAA Equalization
  • What Hi-Fi? Award winner 2017/2018/2019/2020/2021
  • Lifetime warranty against manufacture defects
Fono MM MK5 icon

TECHNICAL SPECIFICATIONS

    Input Sensitivity

    1.7 mV for 200 mV Output

    Input Loading

    47 kΩ in parallel with 100 pF

    Maximum Input Level

    60 mV at 1 kHz

    Gain

    41.4 dB at 1 kHz

    Output Impedance

    200 Ω

    Recommended Minimum Output Load Resistance

    5 kΩ

    Frequency response (50KΩ output load)

    15 Hz (-3 dB) to 100 kHz (-0.2 dB)

    RIAA Accuracy (50 kΩ Output Load)

    Better than ±0.2 dB 100 Hz to 100 kHz

    Power Requirements

    24 V AC at 80 mA maximum

  • For full technical specifications, download FONO MM MK5 USER MANUAL below.
