Lumin P1 Mini

The Lumin P1 Mini distills the acclaimed P1's capabilities into a refined, space-conscious design without compromising performance. This versatile component functions seamlessly as a streamer, DAC, pre-amplifier, or integrated solution. Five input options—USB, HDMI, SPDIF optical, RCA, and analogue—accommodate virtually any audio or video source. Built on X1 Heritage technology, it features dual Femto crystal oscillators with proprietary FPGA clock distribution, dual ES9028PRO DACs, and optical fibre networking for complete isolation from network interference. Support for DSD512 and PCM384 ensures compatibility with high-resolution formats. The internal toroidal linear power supply and LEEDH lossless volume processing deliver refined sound quality. Whether assembling a dedicated streaming system, consolidating multiple stereo sources, or integrating a two-channel TV setup via HDMI ARC, the P1 Mini provides the flexibility and sonic performance expected from LUMIN's flagship lineage.

SPECIFICATION

P1 MINI SPECIFICATION HIGHLIGHTS

• NETWORK PLAYBACK:
  • Up to DSD512
  • Up to 384 kHz, 16–32-bit, Stereo
  • MQA Full Decoding
• UPSAMPLING RATES & BIT DEPTHS:
  • DSD128 upsampling option for all files
  • PCM 384kHz upsampling option for all files
• DIGITAL INPUT:
  • USB:
    • USB Audio Class 2 Compatible
    • WINDOWS 10 (Release 1703 or above) / Mac OSX or above
    • DoP 128 support
    • PCM 44.1–384 kHz, 16 / 32-bit, Stereo
  • OPTICAL/SPDIF:
    • PCM 44.1 kHz–192 kHz, 16–24-bit
    • DSD64 (DoP64, DSD over PCM)
  • HDMI:
    • PCM 2.0 Audio support
    • 4K Video Passthrough
• DIGITAL OUTPUT:
  • USB:
    • Native DSD512 support
    • PCM 44.1–384 kHz, 16–32-bit, Stereo
  • BNC SPDIF:
    • PCM 44.1 kHz–192 kHz, 16–24-bit
    • DSD64 (DoP64, DSD over PCM)
  • HDMI:(HDMI PASSTHROUGH AND ARC SUPPORT)
    • PCM 2.0 Audio support
    • 4K Video Passthrough
    • ARC (Audio Return Channel) support
• ANALOGUE INPUT:
  • RCA Stereo x1
• ANALOG OUTPUT:
  • Dual ESS SABRE³² ES9028Pro DAC chips
  • Fully balanced layout with high-quality components
  • Femto Clock System with precision FPGA distribution
• OPTICAL NETWORK:
  • Industry-standard Gigabit SFP
  • 1000Base-T Gigabit Ethernet
  • Adapter may be needed for your particular switch/cables
  • Use simultaneously with RJ45 (e.g. connect one to router and one to LUMIN L1 or NAS)
• POWER SUPPLY:
  • Internal toroidal linear
  • Low-noise linear regulator
• PHYSICAL:
  • FINISH:
    • Black anodised aluminium
    • Raw anodised aluminium
    LUMIN (SOLID ALUMINIUM CHASSIS):
    • 400mm (W), 314mm (D), 77mm (H), 7kg
