The A5 feat. Magico's 5-inch pure midrange driver enhanced cone technology & Mundorf's new M-Resist Ultra foils, plus it's signature 6061 aluminum & Elliptical Symmetry Crossover. Brushed black anodized aluminum finish.
New bass drivers with advanced new sandwich cones
The Magico A5 Loudspeakers bring you a unique audio experience. Crafted from signature 6061 aluminum with a brushed black anodized aluminum finish, and featuring the innovative 5-inch pure midrange driver enhanced cone technology and Mundorf's new M-Resist Ultra foils, the A5 will offer you clear, precise sound with amazing accuracy.
New five-inch pure midrange driver
The new 5-inch full-cone midrange driver enables wider dispersion and greater midrange transparency. Like the bass driver, the midrange also incorporates an advanced Graphene carbon fiber sandwich cone. A new foam surround helps achieve ideal cone/surround integration, faster settling time and impressively low distortion. The all-new motor system uses a pure Titanium voice coil. The super stabilized magnetic field and pure copper pole cap minimize eddy currents and maximize efficiency. This latest midrange driver sets new benchmarks of measured performance.
High frequency driver
Based on the fundamental design platform and geometry of the M-Series tweeters and shared with the other members of the A-Series, the tweeter incorporates a pure beryllium-diaphragm with an optimized 28-mm dome. Magico encases the customized neodymium motor system in an engineered back chamber with the company’s most advanced damping materials. This enables ultra-low distortion, high power handling, massive dynamic capabilities and extended linear voice coil movement
Crossover debuts the Mundorf M-Resist Ultra foil resistors
Magico acoustically integrates all five drivers with the proprietary Elliptical Symmetry Crossover topology built with state-of-the-art components from Mundorf EB Gmbh of Cologne, Germany. The A5 will be the first product in the world to offer Mundorf’s new M-Resist Ultra foil resistors. Now perfected after years of development, the new resistors deliver greater power handling, transparency and liquidity. The 3-way network features a 24 dB per octave Linkwitz-Riley filter that maximizes frequency bandwidth while preserving phase linearity and minimizing intermodulation distortion.
Aircraft-grade aluminum enclosure
Weighing in at 180 pounds each, the A5 features a massive, sealed enclosure machined entirely of 6061-T6 aircraft-grade aluminum, the same material and construction methods as in Magico’s acclaimed Q-Series. Complex internal bracing helps stiffen the entire enclosure and minimize resonance. A dedicated sub-enclosure houses the midrange driver, protecting it from the extensive back wave energy of the bass drivers. The aluminum has an elegant, brushed black anodized finish.
