Spec description
Cable Type- Screened 3 care cable
Conductor
HOT- D.U.C.C Stressfree 7N Cu MEXCEL / 0.32 φ x 50
COLD- D.U.C.C Stressfree 7N Cu MEXCEL / 0.32 φ x 50
GROUND- Super-anneal 4.5N Cu / 0.32 φ x 50
Conductor jacket- Polymer polyolefin
Insulation- Polymeric polyolefin-hybrid (polyolefin + tungsten, amorphous, and carbon powder)
Shield- Polyurethane enameled 4N Cu braid with Special shielding technology
Outer Jacket- UV-resistant polyurethane
External Diameter- 16mm
Resistance- 2.0m Ohms/m
Capacitance- 10pF/m
Maximum ampacity- 50 Ampere
Connector Types- IEC / Wall plugs US
Connector - Esoteric ultimate power plug / IEC connector with beryllium copper contact elements (silver + rhodium plating)
Standard sales units/lengths- 1.5m* x1
Custom lengths of this power cord, made to order, can be manufactured at extra cost
